Heavy Duty Dry Cleaning Machine With Distillation Tank Laundromats Business 16kg

Heavy Duty Dry Cleaning Machine With Distillation Tank Laundromats Business 16kg

  • Heavy Duty Dry Cleaning Machine With Distillation Tank Laundromats Business 16kg
  • Heavy Duty Dry Cleaning Machine With Distillation Tank Laundromats Business 16kg
Heavy Duty Dry Cleaning Machine With Distillation Tank Laundromats Business 16kg
Product Details:
Place of Origin: Shanghai ,China
Brand Name: Laijie
Certification: CE
Model Number: GXZQ-16
Payment & Shipping Terms:
Minimum Order Quantity: 1 piece
Price: Negotiable
Packaging Details: Plywood packing
Delivery Time: 15 days after received payment
Payment Terms: D/A, L/C, , D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000 pieces per year
Contact Now
Detailed Product Description
Product Name: 16kg Heavy Duty Dry Cleaning Machine Capacity: 8kg 10kg 12kg 16kg
Type: Heavy Duty Operation: Automatic Or Manual Dry Cleaning Machine
Installation: 100% Free Standing Hs Code: 84511000 Dry Cleaning Machine
Control: Full-automatic Function: Dry Cleaning
Application: Laundromats Business
High Light:

16kg Heavy Duty Dry Cleaning Machine

,

Distillation Tank Dry Cleaning Machine

,

Laundromats Dry Wash Machine

16kg Heavy Duty Dry Cleaning Machine With Distillation Tank Laundromats Business



1. This Heavy Duty Dry Cleaning Machine owns washing, extracting, and drying functions.
2. Combines the performance the advantage of brand-name dry cleaning machines of Germany, Italy and other countries.

3. Easy to operate, repair and testing more convenient.Dry cleaning machine all stainless steel for high-quality materials, selection of imported components.
4. Heavy Duty Dry Cleaning Machine is fully closed fully automatic type dry washing machine, it have recycle working system, save solvent (perchloroethylene), no pollution to the air, no harm to the users.

Product characteristics :

1. Steam heating and electric heating for choice.

2. Intelligent cycle washing and refrigeration recovery system.

3. Pipeline and air duct are made of 304 stainless steel with high efficiency and corrosion resistance.

4. All pneumatic valve control, convenient and fast.

5. Pneumatic switch door, reliable anti-leakage, liquid-water separation transparent device real-time observation more clearly.

6. Unique large distillation tank system, distillation recovery faster.

7. The drum is made of 304 stainless steel by precision stamping, and the concave design becomes more and more new.

8. Computer LCD display, the whole process of real-time display operation status is simple to use.

9. Nylon mesh activated carbon filter removes pigments and residues from solvents.

Specification :

Model GXZQ-8 GXZQ-10 GXZQ-12 GXZQ-16
Rated capacity (Kg) 8 10 12 16
Drum Diameter (mm) 718 718 718 718
Capacity(L)   147 174 196 250
Drum Dept (mm) 360 430 480 600
Cleaing speed (R/min) 38 (Adjustable) 38 (Adjustable) 38 (Adjustable) 38 (Adjustable)
Spinning speed (r/min) 400 (Adjustable) 400 (Adjustable) 400 (Adjustable) 400 (Adjustable)
Liquid tank 1 (L) 90 90 90 90
liquid tank 2 (L) 80 80 80 80
liquid tank 3 (L) 98 98 98 100
Controling program 30 30 30 30
Time of cycle (min) 40 40 40 40
Distillation tank capacity (L) 100 100 100 120
Distillation speed(L/h) 80 80 80 100
Washing motor power rating (KW) 1.5 1.5 1.5 2.2
Spinninging motor power rating (KW) 2.2 2.2 2.2 3
Liquid pump power rating (KW) 0.55 0.55 0.55 0.55
Air blower power rating (KW) 0.55 0.55 0.55 0.55
Drying capacity 6 6 6 6
Distillation power 6 6 6 6
Compressor power rating 2.6 2.6 2.6 2.6
In-let water pressure (Mpa) 0.2-0.4 0.2-0.4 0.2-0.4 0.2-0.4
Compressed pressure (Mpa) 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6
Steam pressure (Mpa ) 0.4-0.5 0.45-0.55 0.45-0.55 0.45-0.55
Install power Steam type (kw) 3 3 3 4
Electric type (kw) 9 9 11 11
Rated voltage (V) 220/380 220/380 220/380 220/380
Dimension (W *L*H mm) 1800*1300*2100 1800*1360*2100 1800*1360*2100 1844*1440*2100
Weight (KG) 800 800 800 1000





What is the advantage of Fully enclosed dry cleaning machine ?

(1) The dissolution spectrum of tetrachloroethylene is relatively broad, which can dissolve a variety of fats, oils, tar, rubber, natural resin, PVC resin, etc. It can remove a variety of greasy dirt without damage to all kinds of clothes.



(2) Non combustible, non explosive, no flash point, safe in use Fully reliable.



(3) Low boiling point, easy to recycle and reduce operating costs.



(4) The ratio is large, which is conducive to the utilization of impact kinetic energy and the improvement of washing cleanliness in the washing process.



(5) It is low toxic to human respiratory system, skin and mucous membrane, and excessive inhalation can cause injury.



(6) There are many acidification trends, which need to be sealed, kept at low temperature and away from light, and it is not suitable for large quantities of long-term storage



Heavy Duty Dry Cleaning Machine With Distillation Tank Laundromats Business 16kg 0

Heavy Duty Dry Cleaning Machine With Distillation Tank Laundromats Business 16kg 1



Heavy Duty Dry Cleaning Machine With Distillation Tank Laundromats Business 16kg 2



Our main products are industrial washer extractor,automatic dryer,Hydro extractor ,Ironing machine ,folding machine and other laundry equipment.

We have cooperated with trading companies and exported products to the United States, Middle east , Vietnam, Myanmar ,Canada, Germany, Spain, Pakistan, Malaysia, Indonesia, South Africa, Tanzania, Chile, more than 30 countries.
