Place of Origin:
1. Steam heating and electric heating for choice.
2. Intelligent cycle washing and refrigeration recovery system.
3. Pipeline and air duct are made of 304 stainless steel with high efficiency and corrosion resistance.
4. All pneumatic valve control, convenient and fast.
5. Pneumatic switch door, reliable anti-leakage, liquid-water separation transparent device real-time observation more clearly.
6. Unique large distillation tank system, distillation recovery faster.
7. The drum is made of 304 stainless steel by precision stamping, and the concave design becomes more and more new.
8. Computer LCD display, the whole process of real-time display operation status is simple to use.
9. Nylon mesh activated carbon filter removes pigments and residues from solvents.
|Rated capacity (Kg)||8||10||12||16|
|Drum Diameter (mm)||718||718||718||718|
|Drum Dept (mm)||360||430||480||600|
|Cleaing speed (R/min)||38 (Adjustable)||38 (Adjustable)||38 (Adjustable)||38 (Adjustable)|
|Spinning speed (r/min)||400 (Adjustable)||400 (Adjustable)||400 (Adjustable)||400 (Adjustable)|
|Liquid tank 1 (L)||90||90||90||90|
|liquid tank 2 (L)||80||80||80||80|
|liquid tank 3 (L)||98||98||98||100|
|Time of cycle (min)||40||40||40||40|
|Distillation tank capacity (L)||100||100||100||120|
|Washing motor power rating (KW)||1.5||1.5||1.5||2.2|
|Spinninging motor power rating (KW)||2.2||2.2||2.2||3|
|Liquid pump power rating (KW)||0.55||0.55||0.55||0.55|
|Air blower power rating (KW)||0.55||0.55||0.55||0.55|
|Compressor power rating||2.6||2.6||2.6||2.6|
|In-let water pressure (Mpa)||0.2-0.4||0.2-0.4||0.2-0.4||0.2-0.4|
|Compressed pressure (Mpa)||0.4-0.6||0.4-0.6||0.4-0.6||0.4-0.6|
|Steam pressure (Mpa )||0.4-0.5||0.45-0.55||0.45-0.55||0.45-0.55|
|Install power||Steam type (kw)||3||3||3||4|
|Electric type (kw)||9||9||11||11|
|Rated voltage (V)||220/380||220/380||220/380||220/380|
|Dimension (W *L*H mm)||1800*1300*2100||1800*1360*2100||1800*1360*2100||1844*1440*2100|
(1) The dissolution spectrum of tetrachloroethylene is relatively broad, which can dissolve a variety of fats, oils, tar, rubber, natural resin, PVC resin, etc. It can remove a variety of greasy dirt without damage to all kinds of clothes.
(2) Non combustible, non explosive, no flash point, safe in use Fully reliable.
(3) Low boiling point, easy to recycle and reduce operating costs.
(4) The ratio is large, which is conducive to the utilization of impact kinetic energy and the improvement of washing cleanliness in the washing process.
(5) It is low toxic to human respiratory system, skin and mucous membrane, and excessive inhalation can cause injury.
(6) There are many acidification trends, which need to be sealed, kept at low temperature and away from light, and it is not suitable for large quantities of long-term storage
Our main products are industrial washer extractor,automatic dryer,Hydro extractor ,Ironing machine ,folding machine and other laundry equipment.
We have cooperated with trading companies and exported products to the United States, Middle east , Vietnam, Myanmar ,Canada, Germany, Spain, Pakistan, Malaysia, Indonesia, South Africa, Tanzania, Chile, more than 30 countries.
